3 Upgrading the System

This chapter describes how to upgrade an InterServe 8000 server by adding memory, adding
processors, converting from non-RAID to RAID, adding option boards, and adding SCSI drives.

Before You Begin

Follow the instructions in Chapter 1 for opening the unit to access the internal components.
WARNING Heed all warnings and cautions in the accessing, servicing and upgrading instructions.
Personal injury and damage to equipment can occur if documented procedures are not
followed.
CAUTION The system produces high-leakage current. Flip the circuit breaker (if included) to the OFF position
when servicing or upgrading the base unit.
CAUTION Use an antistatic wrist strap for all servicing procedures to avoid the possibility of electrostatic
discharge (ESD). ESD can damage components inside the system.

Adding Memory

The following memory kits are available for adding memory to the system. Each memory kit contains
four SIMMs and a disposable antistatic wrist strap.
Kit Number
FMEM149
FMEM150
FMEM151
The following table defines the InterServe 8000 memory upgrades.
Base Memory
64 MB
128 MB
256 MB
NOTE Base memory uses four SIMMs. The first upgrade adds four SIMMs, and subsequent upgrades add
eight SIMMs (two upgrade kits).
CAUTION System memory modules available from Intergraph have been certified for use with Intergraph
computers at extremes of temperature and system load to ensure reliable performance. System
memory modules available from other vendors may not function properly or reliably in your Intergraph
computer.
Size of Each SIMM
16 MB (4Mx36)
32 MB (8Mx36)
64 MB (16Mx36)
First Upgrade Subsequent Upgrades
64 MB 128 MB
128 MB 256 MB
256 MB 512 MB
Total Upgrade Size
64 MB
128 MB
256 MB
Maximum Memory
512 MB
1 GB
2 GB
