68
J22: MCBL206A, CD-ROM Drive and Floppy Disk Drive
Pin
Signal
1
+12V
2
Ground
3
Ground
4
VCC, +5v
J24, J26: MCBL050A, RAID Power, JP5
Pin
Signal
1
+12V
2
Ground
3
Ground
4
VCC, +5v
J25: MCBL085A, Auxiliary Drives
Pin
Signal
1
+12V
2
Ground
3
Ground
4
VCC, +5v
Wire Color
Yellow
Black
Black
Red
Wire Color
Yellow
Black
Black
Red
Wire Color
Yellow
Black
Black
Red
