MERLIN LEGEND Communications System Release 7.0
System Planning 555-670-112
2 Control Unit Configuration
Planning Module Placement
This section contains instructions for each of these tasks.
For information about calculating unit load requirements, see
Load Calculation."
For detailed information about modules and their specifications (including line/
trunk and extension capacity), see the descriptions of hardware components
contained in the Pocket Reference.
Forms Needed
Equipment List (if available)
Form 1, System Planning

Capacity for Lines/Trunks

Line/trunk capacity is the number of lines/trunks that can be connected to the
control unit. This section contains instructions for calculating the systems capacity
for lines/trunks, according to the system's module types.
Planning Form Instructions
1. In the table in the Line/Trunk Capacity section of Form 1, System Planning,
fill in the number of each type of line/trunk module on the appropriate line of
the Number of Modules column.
2. Add the column and record the result at the bottom of the column on the
System Totals line.
3. For each module type noted, multiply the value in the Number of Modules
column by the value in the Trunks Supported by Module column; write the
results in the appropriate row under Total Trunks by Module Type.
4. Add the column and record the total line/trunk capacity of the system at the
bottom of the column, on the System Totals line.

Capacity for Extensions

Extension capacity is the number of extensions that can be connected to the
control unit. In most cases, the number of physical jacks on the modules indicates
capacity. Most loop-start and ground-start modules have one or two power-failure
transfer (PFT) jacks connected to a single-line telephone in case of a power
failure, and not counted in system capacity. Every four line jacks has one
associated PFT jack.
One extension number is automatically assigned to each extension jack, whether
or not equipment is connected to it, except for the following modules:
