MERLIN LEGEND Communications System Release 7.0
System Planning 555-670-112
3 Lines/Trunks
Identifying Line/Trunk Jacks
Planning Form Instructions
1. Review the floor plan and Equipment List (if available) to confirm the
auxiliary equipment to be connected.
2. At the top of Form 2c, fill in the line/trunk numbers for each type of auxiliary
equipment planned:

Function Information

If the system has a Voice Messaging System (such as Messaging 2000), you can
use the Function column to indicate which service is available for those jacks. You
can also use this column to indicate whether a jack connects a personal line and,
therefore, has an owner.
Planning Form Instructions
In the Function column of Form 2c, do either of the following:
If a jack is used for a special purpose, note the purpose. For example, if the
system has Messaging 2000 with fax capability, indicate the service by
writing one of the following for the appropriate jack:
For Music-On-Hold, write the line/trunk number of the line/trunk jack
designated for this equipment, and identify the music source (tape
player, radio, or Music-On-Hold) on the Music-On-Hold line.
NOTE:
If the system uses equipment that rebroadcasts music or
other copyrighted materials, the customer may be required to
obtain a copyright license from, and pay license fees to, a
third party such as the American Society of Composers,
Artists, and Producers (ASCAP) or Broadcast Music
Incorporated (BMI). The Magic On Hold system, which
does not require such a license, can be purchased from a
Lucent Technologies representative.
For Loudspeaker Paging, on the appropriate row, write the line/trunk
numbers (maximum of 3) of the line/trunk jack or jacks designated
for the paging equipment.
For Maintenance Alarm, on the appropriate row, write the line/trunk
number of the line/trunk jack designated for the Maintenance Alarm
external alert.
NOTE:
The last item, Loop-Start Reliable Disconnect, refers to a line/trunk
option and is completed later in this chapter.
— For Automated Attendant, write
