MERLIN LEGEND Communications System Release 7.0
System Planning 555-670-112
5 Data Communications
Creating Data Hunt Groups

Guidelines

Use the following guidelines for the procedure in this section:
Members of a DHG must be extension jacks of the same type: all analog or
all MLX.
You can assign up to 32 DHGs or calling groups, or a combination of both
types. Each DHG can have a maximum of 20 members and each data
station can be a member of only one DHG.
You can designate particular lines/trunks or pools (Hybrid/PBX mode only)
to ring directly into a DHG. Incoming calls on a given line/trunk, however,
can be directed to only one DHG.
Extension numbers 770–791 and 7920–7929 are reserved automatically
for calling groups and DHGs. If you want to change the extension numbers
assigned to a DHG, see the information about reassigning extension
numbers described in
considerations apply to data stations and voice extensions.
Forms Needed
Form 2a, System Numbering: Extension Jacks
Form 2c, System Numbering: Line/Trunk Jacks
If the system includes voice calling groups, Form 7d, Group Calling
If you plan to renumber the factory-set extensions, Form 2d, System
Numbering: Special Renumbers
Planning Form Instructions
Make enough copies of Data Form 2, Data Hunt Groups, for the number of data
hunt groups you plan. For each DHG:
1. Write the group number (1–32) in the Group Number space.
2. Write the name of the group in the Group ID space.
3. Write the factory-set extension number for the DHG in the space provided.
4. If you want to reassign the factory-set extension number for the DHG, write
the new number in the Renumber to space. Also, write the new extension
number you want to reassign in the calling group or DHG on Form 2d,
System Numbering: Special Renumber.
5. Under the Purpose of Group heading, indicate the group use: local host
computer access workstation, LAN access, and so forth.
Chapter
NOTE:
Check all pages of Form 7d to be sure that you have not assigned
the extension to a voice calling group.
5
2, ''Control Unit Configuration." The same
Issue 1
April 1999
5-38
