AT&T MERLIN LEGEND System Reference Manual page 581

General Telephone Programming Instructions
Programming Analog
Multiline Telephones
Programming MLX-10
Telephones
B-2
General Telephone Programming Instructions
Step
1. Label the button
Note: Skip this step
if the feature does
not get programmed
onto a button.
2. Begin programming
3. Select the feature
4 . End programming
Step
1.
Label the button
Note: Skip this step
if the feature does
not get programmed
onto a button.
2.
Begin programming
3.
Select the feature
4.
End programming
Action
Remove the clear label cover from the
telephone by inserting the end of a paper clip in
the notch at the top of the cover.
Write the feature name on the card next to the
button to be programmed.
Replace the cover.
Slide the T/P switch on the side of the telephone
to P.
Press the button you labeled.
a
If you have display, it shows the name of the feature
currently programmed on the button. If no feature is
programmed, the display indicates the button is
Blank.
Note: If the feature does not get programmed
onto a button, press any line button. This does
not affect the button in anyway.
Dial the programming code.
The feature is programmed.
Slide the T/P switch to the center position.
Action
Remove the clear label cover from the
telephone by pulling upon the tab that extends
from the top of the cover.
Write the feature name on the card next to the
button to be programmed.
Replace the cover.
Press Feature then dial 00.
Press the button you labeled.
Note: If the feature does not get programmed
onto a button, press any line button. This does
not affect the button in anyway.
Dial the programming code.
The feature is programmed.
Press Feature then dial * 00.
