AT&T MERLIN LEGEND System Reference Manual page 202

Features
Table 2-11 Continued
Feature/Function
Desccription
Making Calls, If a user dials 0 to reach the
continued
system operator or, in the
Hybrid/PBX mode, dials the listed
directory number (the QCC queue
extension), the display identifies
the number as the system
operator. When the call is sent
immediately to a system operator
without going through the QCC
queue, the extension or label for
the system operator receiving the
call is shown instead.
When a user goes off-hook on a
line or pool button, the display
shows the label (if programmed) for
the line or pool that was selected.
On MLX telephones, this information
remains on the display. On analog
multiline telephones, the line label
is erased when the user begins
dialing. If the user dials more than
15 digits on an MLX telephone and
more than 16 digits on an analog
multiline telephone, the remaining
digits are shown on page 2.
Messaging When users try to send a message
to a telephone whose message
box is full, they see a feedback
message on the display.
When a user tries to retrieve
messages and the message box is
empty, a message appears to
indicate there are no messages.
When a user has a message, the
display shows the name or
extension number (if no alpha label
is programmed) of the caller and,
on MLX telephones, the time and
date the message was left.
Messages can be sent by co-
workers and by outside callers if
the telephone has voice mail, by
the system operator, or by a fax
Continued machine.
Analog Multiline
MLX Display
Display
Operatr
Operatr
5551234 FX-NYC 5551234
Message Box Message Box Full
Full
No Messages No Messages
Display 2-153
