Message Status Operation-Led Meanings - AT&T MERLIN LEGEND System Reference Manual

Features
For calling group or CMS supevisor operation or for hotel Extension Status,
while the position is in message status operation, the red LED next to a DSS
button for a user extension indicates whether or not a user is on a call (off-hook),
has no call active (on-hook), or has the Do Not Disturb feature active. On a DSS
button for a calling group extension, the red LED indicates the status of the
queue. For a DSS button for a pool dial-out code, the red LED indicates trunk
availability.
The meanings of the red LEDs next to the DSS buttons while the system
operator position is in the message status operation are shown in Table 2-9.
Table 2-9 Message Status Operation-LED Meanings
LED Extension
Operation Status Type
Normal Off User
call
handling
All other types Not applicable; red LED is always off.
On User
Supervisor Off User
or Hotel
Extension
status
Line/trunk
number
Pool dial+out
code
Calling group
Paging group
Operator Park
zone
ARS, Remote
Access,
Listed Direc-
tory Number
Meaning
A system operator has not turned on the
message-waiting LED.
A system operator turned on the
message-waiting LED to indicate a
message is waiting.
The person is not on the telephone and is
not using Do Not Disturb.
The line/trunk is not in use.
At least one trunk is available for making
an outside call.
The calling group queue is below the
allowable threshold.
The group is available for making a group
announcement.
A call is not parked on this park zone
code.
Not applicable; red LED is always off.
Direct Station Selector 2-129
