Chapter 13 Configuring STP
•
•
•
•
•

Default Spanning-Tree Configuration

Table 13-3
Table 13-3 Default Spanning-Tree Configuration
Feature
Enable state
Spanning-tree mode
Switch priority
Spanning-tree port priority (configurable on a per-interface basis) 128.
Spanning-tree port cost (configurable on a per-interface basis)
Spanning-tree VLAN port priority (configurable on a per-VLAN
basis)
Spanning-tree VLAN port cost (configurable on a per-VLAN
basis)
Spanning-tree timers

Spanning-Tree Configuration Guidelines

If more VLANs are defined than there are spanning-tree instances, you can enable PVST+ or rapid
PVST+ on STP ports s in only 128 VLANs on the switch. The remaining VLANs operate with spanning
tree disabled. However, you can map multiple VLANs to the same spanning-tree instances by using
MSTP. For more information, see
If 128 instances of spanning tree are already in use, you can disable spanning tree on STP ports in one
of the VLANs and then enable it on the VLAN where you want it to run. Use the no spanning-tree vlan
vlan-id global configuration command to disable spanning tree on a specific VLAN, and use the
spanning-tree vlan vlan-id global configuration command to enable spanning tree on the desired
VLAN.
OL-23400-01
Configuring a Secondary Root Switch, page 13-15
Configuring Port Priority, page 13-16
Configuring Path Cost, page 13-18
Configuring the Switch Priority of a VLAN, page 13-19
Configuring Spanning-Tree Timers, page 13-20
shows the default spanning-tree configuration.
(optional)
(optional)
(optional)
(optional)
Default Setting
Enabled on ports in VLAN 1.
Rapid PVST+
Rapid PVST+ interoperates with PVST and PVST+.
MSTP is disabled.
32768.
1000 Mbps: 4.
100 Mbps: 19.
10 Mbps: 100.
128.
1000 Mbps: 4.
100 Mbps: 19.
10 Mbps: 100.
Hello time: 2 seconds.
Forward-delay time: 15 seconds.
Maximum-aging time: 20 seconds.
Chapter 14, "Configuring MSTP."
Cisco ME 3800X and 3600X Switch Software Configuration Guide
Configuring Spanning-Tree Features
(optional)
