Preventing Autonegotiation Mismatches

You are prompted to start the setup program. To continue with password recovery, enter N at the prompt:
Continue with the configuration dialog? [yes/no]: N
Step 5 At the switch prompt, enter privileged EXEC mode:
Switch> enable
Enter global configuration mode:
Step 6
Switch# configure terminal
Change the password:
Step 7
Switch (config)# enable secret password
The secret password can be from 1 to 25 alphanumeric characters, can start with a number, is case
sensitive, and allows spaces but ignores leading spaces.
Return to privileged EXEC mode:
Step 8
Switch (config)# exit
Switch#
Write the running configuration to the startup configuration file:
Step 9
Switch# copy running-config startup-config
The new password is now in the startup configuration.
Note
You must now reconfigure the switch. If the system administrator has the backup switch and VLAN
Step 10
configuration files available, you should use those.
Preventing Autonegotiation Mismatches
The IEEE 802.3ab autonegotiation protocol manages the switch settings for speed (10, 100, and
1000 Mbps, excluding SFP module ports) and duplex (half or full). There are situations when this
protocol can incorrectly align these settings, reducing performance. A mismatch occurs under these
circumstances:
•
•
To maximize switch performance and ensure a link, follow one of these guidelines when changing the
settings for duplex and speed:
•
•
Cisco ME 3800X and 3600X Switch Software Configuration Guide
35-6
This procedure is likely to leave your switch virtual interface in a shutdown state. You can
identify this interface by entering the show running-config privileged EXEC command. To
re-enable the interface, enter the interface vlan vlan-id global configuration command, and
specify the VLAN ID of the shutdown interface. With the switch in interface configuration
mode, enter the no shutdown command.
A manually set speed or duplex parameter is different from the manually set speed or duplex
parameter on the connected port.
A port is set to autonegotiate, and the connected port is set to full duplex with no autonegotiation.
Let both ports autonegotiate both speed and duplex.
Manually set the speed and duplex parameters for the ports on both ends of the connection.
