Chapter 25 Configuring SNMP
Command
Step 3
snmp-server group groupname {v1 | v2c |
v3 {auth | noauth | priv}} [read readview]
[write writeview] [notify notifyview]
[access access-list]
OL-23400-01
Purpose
Configure a new SNMP group on the remote device.
For groupname, specify the name of the group.
•
Specify a security model:
•
v1 is the least secure of the possible security models.
–
v2c is the second least secure model. It allows transmission
–
of informs and integers twice the normal width.
v3, the most secure, requires you to select an authentication
–
level:
auth—Enables the Message Digest 5 (MD5) and the Secure
Hash Algorithm (SHA) packet authentication.
noauth—Enables the noAuthNoPriv security level. This is
the default if no keyword is specified.
priv—Enables Data Encryption Standard (DES) packet
encryption (also called privacy).
The priv keyword is available only when the cryptographic
Note
software image is installed.
(Optional) Enter read readview with a string (not to exceed 64
•
characters) that is the name of the view in which you can only
view the contents of the agent.
• (Optional) Enter write writeview with a string (not to exceed 64
characters) that is the name of the view in which you enter data
and configure the contents of the agent.
(Optional) Enter notify notifyview with a string (not to exceed 64
•
characters) that is the name of the view in which you specify a
notify, inform, or trap.
• (Optional) Enter access access-list with a string (not to exceed 64
characters) that is the name of the access list.
Cisco ME 3800X and 3600X Switch Software Configuration Guide
Configuring SNMP
25-11
