Cisco 3845 - Security Bundle Router Software Manual page 438

Configuring SNMP
Table 25-5 Switch Notification Types (continued)
Notification Type Keyword
stpx
syslog
tty
udp-port
vlan-membership
vlancreate
vlandelete
Note Though visible in the command-line help strings, the fru-ctrl and vtp keywords are not supported. The
snmp-server enable informs global configuration command is not supported. To enable the sending of
SNMP inform notifications, use the snmp-server enable traps global configuration command
combined with the snmp-server host host-addr informs global configuration command.
You can use the snmp-server host global configuration command to a specific host to receive the
notification types listed in
Beginning in privileged EXEC mode, follow these steps to configure the switch to send traps or informs
to a host:
Command
Step 1
configure terminal
Step 2
snmp-server engineID remote
ip-address engineid-string
Step 3
snmp-server user username
groupname {remote host [udp-port
port]} {v1 [access access-list] | v2c
[access access-list] | v3 [encrypted]
[access access-list] [auth {md5 | sha}
auth-password]}
Step 4
snmp-server group groupname {v1 |
v2c | v3 {auth | noauth | priv}} [read
readview] [write writeview] [notify
notifyview] [access access-list]
Cisco ME 3800X and 3600X Switch Software Configuration Guide
25-14
Description
Generates SNMP STP Extended MIB traps.
Generates SNMP syslog traps.
Generates a trap for TCP connections. This trap is enabled by default.
Generates a trap for notification of host UDP port number change (default is port 162).
Generates a trap for SNMP VLAN membership changes.
Generates SNMP VLAN created traps.
Generates SNMP VLAN deleted traps.
Table 25-5.
Purpose
Enter global configuration mode.
Specify the engine ID for the remote host.
Configure an SNMP user to be associated with the remote host created in
Step 2.
Note
Configure an SNMP group.
You cannot configure a remote user for an address without first
configuring the engine ID for the remote host. Otherwise, you
receive an error message, and the command is not executed.
Chapter 25 Configuring SNMP
OL-23400-01
