Configuring Ethernet CFM
Command
Step 12
ethernet cfm mep domain domain-name mpid
identifier port
Step 13 end
Step 14 show ethernet cfm maintenance-points remote
static
Step 15
show ethernet cfm errors [configuration]
Step 16
copy running-config startup-config
Use the no form of each command to remove a configuration or to return to the default settings.
This is a sample configuration for a port MEP:
Switch(config)# ethernet cfm domain abc level 3
Switch(config-ecfm)# service PORTMEP port
Switch(config-ecfm-srv)# mep mpid 222
Switch(config-ecfm-srv)# continuity-check
Switch(config-ecfm-srv)# continuity-check static rmep
Switch(config-ecfm-srv)# exit
Switch(config-ecfm)# exit
Switch(config)# interface gigabitethernet0/1
Switch(config-if)# ethernet cfm mep domain abc mpid 111 port
Switch(config-if)# end

Configuring SNMP Traps

Beginning in privileged EXEC mode, follow these steps to configure traps for Ethernet CFM:
Command
Step 1
configure terminal
Step 2
snmp-server enable traps ethernet cfm cc [mep-up]
[mep-down] [config] [loop] [cross-connect]
Step 3
snmp-server enable traps ethernet cfm crosscheck
[mep-unknown] [mep-missing] [service-up]
Step 4 end
Step 5 show running-config
Step 6 copy running-config startup-config
Use the no form of each command to remove a configuration or to return to the default settings.
Cisco ME 3800X and 3600X Switch Software Configuration Guide
32-14
Chapter 32 Configuring Ethernet OAM, CFM, and E-LMI
Purpose
Configure the interface as a port MEP for the domain.
domain domain-name—Specify the name of the
•
created domain.
• mpid identifier—Enter a maintenance end point
identifier. The identifier must be unique for each
VLAN. The range is 1 to 4094.
Return to privileged EXEC mode.
Verify the configuration.
Enter this command after you enable CFM crosscheck to
display the results of the crosscheck operation. Enter the
configuration keyword to display the configuration error
list.
(Optional) Save your entries in the configuration file.
Purpose
Enter global configuration mode.
(Optional) Enable Ethernet CFM continuity check traps.
(Optional) Enable Ethernet CFM crosscheck traps.
Return to privileged EXEC mode.
Verify your entries.
(Optional) Save your entries in the configuration file.
