Cisco 3845 - Security Bundle Router Software Manual page 633

Chapter 29 Configuring IP Unicast Routing
Command
Step 12
lsp-gen-interval [level-1 | level-2]
lsp-max-wait [lsp-initial-wait
lsp-second-wait]
Step 13
spf-interval [level-1 | level-2]
spf-max-wait [spf-initial-wait
spf-second-wait]
Step 14 prc-interval prc-max-wait
[prc-initial-wait prc-second-wait]
Step 15 log-adjacency-changes [all]
Step 16 lsp-mtu size
Step 17 partition avoidance
Step 18
end
Step 19
show clns
Step 20
copy running-config startup-config
To disable default route generation, use the no default-information originate router configuration
command. Use the no area-password or no domain-password router configuration command to disable
passwords. To disable LSP MTU settings, use the no lsp mtu router configuration command. To return
OL-23400-01
Purpose
(Optional) Set the IS-IS LSP generation throttling timers:
lsp-max-wait—the maximum interval (in seconds) between two
•
consecutive occurrences of an LSP being generated. The range is 1 to
120, the default is 5.
lsp-initial-wait—the initial LSP generation delay (in milliseconds).
•
The range is 1 to 10000; the default is 50.
lsp-second-wait—the hold time between the first and second LSP
•
generation (in milliseconds). The range is 1 to 10000; the default is
5000.
(Optional) Sets IS-IS shortest path first (SPF) throttling timers.
• spf-max-wait—the maximum interval between consecutive SFPs (in
seconds). The range is 1 to 120, the default is 10.
spf-initial-wait—the initial SFP calculation after a topology change (in
•
milliseconds). The range is 1 to 10000; the default is 5500.
spf-second-wait—the holdtime between the first and second SFP
•
calculation (in milliseconds). The range is 1 to 10000; the default is
5500.
(Optional) Sets IS-IS partial route computation (PRC) throttling timers.
prc-max-wait—the maximum interval (in seconds) between two
•
consecutive PRC calculations. The range is 1 to 120; the default is 5.
prc-initial-wait—the initial PRC calculation delay (in milliseconds)
•
after a topology change. The range is 1 to 10,000; the default is 2000.
• prc-second-wait—the hold time between the first and second PRC
calculation (in milliseconds). The range is 1 to 10,000; the default is
5000.
(Optional) Set the router to log IS-IS adjacency state changes. Enter all to
include all changes generated by events that are not related to the
Intermediate System-to-Intermediate System Hellos, including End
System-to-Intermediate System PDUs and link state packets (LSPs).
(Optional) Specify the maximum LSP packet size in bytes. The range is 128
to 4352; the default is 1497 bytes.
Note If any link in the network has a reduced MTU size, you must change
the LSP MTU size on all routers in the network.
(Optional) Causes an IS-IS Level 1-2 border router to stop advertising the
Level 1 area prefix into the Level 2 backbone when full connectivity is lost
among the border router, all adjacent level 1 routers, and end hosts.
Return to privileged EXEC mode.
Verify your entries.
(Optional) Save your entries in the configuration file.
Cisco ME 3800X and 3600X Switch Software Configuration Guide
Configuring ISO CLNS Routing
29-67
