Chapter 4 Configuring Cisco IOS Configuration Engine
•

Enabling an Initial Configuration

Beginning in privileged EXEC mode, follow these steps to enable the CNS configuration agent and
initiate an initial configuration on the switch:
Command
Step 1 configure terminal
Step 2
cns template connect name
Step 3
cli config-text
Step 4
Step 5 exit
Step 6 cns connect name [retries number]
[retry-interval seconds] [sleep seconds]
[timeout seconds]
Step 7
discover {controller controller-type | dlci
[subinterface subinterface-number] | interface
[interface-type] | line line-type}
OL-23400-01
The cns config partial global configuration command enables the Cisco IOS agent and initiates a
partial configuration on the switch. You can then use the Configuration Engine to remotely send
incremental configurations to the switch.
Purpose
Enter global configuration mode.
Enter CNS template connect configuration mode, and specify
the name of the CNS connect template.
Enter a command line for the CNS connect template. Repeat
this step for each command line in the template.
Repeat Steps 2 to 3 to configure another CNS connect template.
Return to global configuration mode.
Enter CNS connect configuration mode, specify the name of the
CNS connect profile, and define the profile parameters. The
switch uses the CNS connect profile to connect to the
Configuration Engine.
Enter the name of the CNS connect profile.
•
(Optional) For retries number, enter the number of
•
connection retries. The range is 1 to 30. The default is 3.
(Optional) For retry-interval seconds, enter the interval
•
between successive connection attempts to the
Configuration Engine. The range is 1 to 40 seconds. The
default is 10 seconds.
(Optional) For sleep seconds, enter the amount of time
•
before which the first connection attempt occurs. The range
is 0 to 250 seconds. The default is 0.
(Optional) For timeout seconds, enter the amount of time
•
after which the connection attempts end. The range is 10 to
2000 seconds. The default is 120.
Specify the interface parameters in the CNS connect profile.
• For controller controller-type, enter the controller type.
For dlci, enter the active data-link connection identifiers
•
(DLCIs).
(Optional) For subinterface subinterface-number, specify
the point-to-point subinterface number that is used to
search for active DLCIs.
For interface [interface-type], enter the type of interface.
•
For line line-type, enter the line type.
•
Cisco ME 3800X and 3600X Switch Software Configuration Guide
Configuring Cisco IOS Agents
4-9
