Chapter 34 Configuring MPLS, MPLS VPN, MPLS OAM, and EoMPLS
You can also use the xconnect logging redundancy global configuration command to track the status
of the xconnect redundancy group. The command generates messages during switchover events.
This example shows pseudowire redundancy.
Switch# show mpls l2transport vc 10
Local intf
-------------
Vl10
Vl10

Support for H-VPLS

The Metro 3800X and Metro 3600X switches support hierarchical VPLS (H-VPLS).
Note This feature requires the ME 3800X Metro Aggregation Access or ME 3800S Scaled Metro Aggregation
Access software license.
H-VPLS uses spoke connections, usually between Layer 2 switches acting as the CE and PE devices at
the service provider's point-of presence (POP). The spoke connections can be either an IEEE 802.1Q
tagged connection or an MPLS LSP.
Figure 34-8
and PE2) configured as neighbors on different sides of an MPLS network. Each switch has multiple
customer Ethernet switches connected to it and is connected to a PE device at the service-provider POP.
With no direct connections, H-VPLS allows the customer switches from PE1 to connect to customer
switches connected to PE2.
Figure 34-8
Control plane
Data plane
OL-23400-01
Local circuit
-------------------------- --------------- ---------- ----------
Eth VLAN 10
Eth VLAN 10
shows two Metro 3800X or Metro 3600X customer-located equipment (CLE) switches (PE1
H-VPLS Configuration Example
CE
PE-CLE
PE1
802.1Q tunnel
EoMPLS
Dest address
1.1.1.1
2.2.2.2
Directed LDP
LDP
PE-POP PE-POP
MPLS
Cisco ME 3800X and 3600X Switch Software Configuration Guide
Support for H-VPLS
VC ID Status
10 UP
10 DOWN
PE-CLE
PE2
802.1Q
CE
34-41
