Back Panel Connectors

Table 2.

NIC LEDs

NIC LED Color
Orange
Green
8
Figure 1. Back Panel Connectors
A. Mouse connector
B. Keyboard connector
C. Parallel Port connector
D. Serial Port connectors
E. Network connector
F. Green NIC LED
G. Orange NIC LED
H. USB connectors
I. Video connector
If it's on If it's blinking
NA
100 Mbps network
connection.
Linked to network, Linked to network, sending or
no network traffic. receiving data.
If it's off
10 Mbps network connection.
Not linked to network.
Description
