linework to door/window assemblies and to apply the settings of a door/window assembly tool to existing door/window
assemblies.
The following palettes contain one or more door/window assembly tools:
Tool Palette
Design palette in the Sample Palette catalog
Design Tool Catalog Doors and Windows
Assemblies
custom tool palettes created by your CAD manager
When you place door/window assemblies using door/window assembly tools, you can use the default settings of the
tool, or you can change settings for any door/window assembly properties that are not controlled by the style.
Creating a Door and Window Assembly
Use this procedure to add a new door/window assembly that has the properties specified in the door/window assembly
tool that you select. To specify settings when you add a door/window assembly, see
Assembly with User-Specified
1 Open the tool palette that contains the door/window assembly tool you want to use, and select the tool.
TIP You may have to scroll to display the desired tool. After you select it, you can move or hide the Properties
palette to expose more of the drawing area.
If necessary, scroll to display the tool that you want to use.
2 Select a wall, or press
Using Door and Window Assembly Tools to Create Door and Window Assemblies | 907
Door and Window
Settings" on page 908.
and then specify the insertion point of the door/window assembly.
ENTER
Door/Window Assembly Tools
Standard door/window assembly style and default settings for other
door/window assembly properties
a large number of door and window assembly styles for many design
uses
door/window assembly styles and properties that your CAD manager
customized for your projects or office standards
Creating a Door and Window
