2 Expand Basic, and expand General.
3 Select a different style.

Changing the Horizontal Direction of a Spiral or U-Shaped Stair

Use this procedure to change the orientation of a spiral stair.
1 Select a spiral or U-shaped stair.
2 Specify the horizontal orientation of the stair:
If you want to
draw the spiral or U-shaped stair in a counterclockwise
direction
draw the spiral or U-shaped stair in a clockwise direction
NOTE This is equivalent to selecting the Flip grip that mirrors the stair around its start point.

Changing the Constraints of a Spiral Stair

Use this procedure to control what constrains the spiral stair by specifying the total degrees or the number of degrees
per tread to use. These fields are available only when you select a spiral-shaped stair to modify.
1 Select a spiral stair.
2 Specify the arc constraint:
If you want to
display the spiral stair with no constraint
specify the total degrees for the stair flight
specify the specific degree for each tread in the stair
3 Specify the Radius of the stair.
1184 | Chapter 25 Stairs
Then
select Counterclockwise for Horizontal Orientation.
select Clockwise for Horizontal Orientation.
Then
select Free for Arc Constraint.
select Total Degrees for Arc Constraint, and enter a value for
Arc Angle.
select Degrees per Tread for Arc Constraint, and enter a value
for Arc Angle.
