Removing Curtain Wall Unit Overrides

Use this procedure to remove curtain wall unit overrides either from the curtain wall unit or the curtain wall unit style.
1 Select the curtain wall unit:
If you want to remove an override
from a curtain wall unit
from the curtain wall unit style
2 Select an override from the list and click Remove.
3 Click OK.

Editing Curtain Wall Units

Most relevant settings for a curtain wall unit are defined in the curtain wall unit style. These include divisions, infills,
frames, and mullions. For information on modifying a curtain wall unit style, see
845.
You can make other changes directly to individual curtain wall units. These changes affect only the curtain wall unit
you select:
Dimensions of a curtain wall unit
Roof and floor line settings
Interference conditions
Cleanup settings
Methods of Editing Curtain Wall Units
AutoCAD Architecture offers several methods for editing curtain wall units:
You can directly edit curtain wall units using grips for dimensions, base height, location, and other physical
characteristics.
You can directly edit curtain wall units using the Edit Grid grip for grid divisions, cells, frames, and mullions. For
more information, see
Profiles for Curtain Wall
You can change curtain wall unit settings on the Properties palette.
You can select editing commands from the context menu for a selected curtain wall unit.

Using Grips to Edit Curtain Wall Units

There are many different curtain wall unit grips. The grips that appear in your drawing when you select a curtain wall
unit are dependent upon the design rules of the curtain wall unit. For more information, see
on page 845.
Editing Curtain Wall Unit Dimensions
Use this procedure to change the dimensions of a curtain wall unit.
1 Select the curtain wall unit.
2 Select the grip for the dimension you want to change.
You can modify the dimensions of the height and length for a curtain wall unit.
In-Place Editing of Curtain Wall Unit Divisions
Units" on page 889 and
Then
select the curtain wall unit, right-click and click Curtain Wall
Unit Properties. Click the Overrides tab.
select the curtain wall unit, right-click, and click Edit Curtain
Wall Unit Style. Click the Overrides tab.
" on page 893,
Overriding Curtain Wall Unit
Removing Curtain Wall Unit Overrides | 895
Curtain Wall Unit Styles" on page
In-Place Editing of Edge
Infills" on page 880.
Curtain Wall Unit Styles"
