If you want to
exit the in-place editing session after saving your changes
7 In the Save Changes dialog box, specify to which division to save the changes:
If you want to
save the changes to the style in the current door/window
assembly division
create an override to the style by saving the changes in a new
door/window assembly division
Removing Door and Window Assembly Overrides
Use this procedure to remove door/window assembly overrides either from the door/window assembly or the
door/window assembly style.
1 Select the door/window assembly:
If you want to
remove an override from a door/window assembly
remove an override from the door/window assembly style
2 Select an override from the list and click Remove.
3 Click OK.

Modifying Element Definitions for Door and Window Assembly Styles

You can modify element definitions using the Design Rules tab of the Door/Window Assembly Style Properties dialog
box. You can access these definitions from the assignments list and from the definitions list:
From the assignments list: Select a grid from the tree view to display the assignments list. Then select an
assignment that uses that definition. Make your changes below the assignment list.
968 | Chapter 20 Door and Window Assemblies
Then
click on the In-Place Edit toolbar. If you edited the
grid by instance, the changes are saved to the design rules
for the individual grid. If you edited the door/window
assembly style, the Save Changes dialog box is displayed.
Then
verify the current division is selected for Save Changes to
Existing Division, and click Save. The changes are made in
the style and affect all door/window assemblies of that style
in the drawing.
click New, enter a name for the new division override, and
click OK. Click Save. The changes are saved as an override to
the style, and affect only the door/window assemblies to
which the override is applied.
Then
select the door/window assembly, expand Advanced in the
Properties palette, and click Overrides.
select the door/window assembly, right-click, and click Edit
Door/Window Assembly Style. Then click the Overrides tab.
