Changing the Alignment of an Anchored Curtain Wall Unit
Use this procedure to change the alignment of a curtain wall unit anchored into a curtain wall.
1 Double-click the anchored curtain wall unit.
2 Expand Location, and click Anchor.
3 Click Allow Variation from Infill Element Definition.
4 Select a new alignment for the curtain wall unit.
For more information, see
5 Click OK.
Changing the Offset of an Anchored Curtain Wall Unit
Use this procedure to change the offset of an anchored curtain wall unit.
1 Double-click the anchored curtain wall unit.
2 Expand Location, and click Anchor.
3 Click Allow Variation from Infill Element Definition.
4 Specify a new offset for the curtain wall unit.
For more information, see
5 Click OK.

Attaching Hyperlinks, Notes, or Files to a Curtain Wall Unit

Use this procedure to enter notes and attach reference files to a curtain wall unit. You can also edit notes and edit or
detach reference files from a curtain wall unit.
1 Double-click the curtain wall unit.
2 On the Properties palette, click the Extended Data tab.
3 To add a hyperlink, click the setting for Hyperlink, and specify the link.
4 To add a note, click the setting for Notes, and enter the text.
5 Click OK.
6 Click under Reference documents, and attach, edit, or detach a reference file:
If you want to
attach a reference file
edit the description of a reference file
edit a reference file
detach a reference file
7 Click OK twice.

Facet Deviation

The smoothness (tesselation) of curved curtain wall edges is controlled by the FACETDEV variable. Specify the facet
deviation to set the number of facets to display on curved objects. This must be set before converting a polyline to a
curtain wall.
The facet deviation is available only on the command line by typing -AecFacetDev.
The number you set as the facet deviation defines the maximum distance from the chord to the arc, the chord being
an edge that is created from faceting the curve, to the true mathematical arc. The facet deviation has a range of greater
than zero (0) and no upper limit.
900 | Chapter 19 Curtain Walls
Specifying an Alignment for a Curtain Wall Unit
Specifying an Offset for a Curtain Wall Unit
Infill" on page 854.
Infill" on page 854.
Then
click Add, select a file, and click Open.
select the file, and click the description. Enter the new text,
and press ENTER.
double-click the reference file name to start its application.
select the file name, and click Delete.
