Window Component

Plan Low Detail

Assigning Materials to a Window Style

Use this procedure to assign materials to the individual components of a window style. When you assign materials to

window components, the components use the display properties of the material. For more information, see

Window Display Components and

You can specify the materials used to display the following components of a window style:

NOTE If a material assignment does not determine the display properties of a window component, you can change the

display properties of the window style as described in

1 Open a tool palette that has a window tool.

2 Right-click a window tool, and click Window Styles.

3 Select the style you want to edit.

4 Click the Display Properties tab.

5 Select the display representation in which you want changes to appear, and select Style Override.

6 If necessary, click

7 Click the Layer/Color/Linetype tab.

8 Select By Material for any component to which you want to assign a material, and click OK.

If the setting for By Material is not available, the display of this component cannot be determined by a

9 Click the Materials tab.

10 Click the component you want to change, and select a different material definition.

You can select any material definition in the current drawing, or click

and assign it to a component.

2D Section/Elevation Linework

Materials" on page 1084.

Specifying the Display Properties of a Window

Material Component

Assigning Materials to a Window Style | 1085

Style" on page 1086.

to create a new material definition
