Specifying Offsets for the Mullions of a Door and Window Assembly
Use this procedure to define mullions that are offset from the start or end of the door/window assembly to lengthen
or shorten the edge or offset in the X or Y direction to shift the edge. For example, you might want to represent butt
glazing by offsetting the mullions to be behind glass panel infills.
Offset
X
Y
Start
End
TIP To quickly identify the start and end of a door/window assembly, select the door/window assembly. The Reverse Direction
grip is displayed near the center of the door/window assembly and points toward the end of the door/window assembly.
1 On the Format menu, click Style Manager.
2 Expand Architectural Objects, and expand Door/Window Assembly Styles.
3 Select a door/window assembly style.
4 Click the Design Rules tab.
5 In the left pane, select Mullions under Element Definitions.
6 Select a mullion definition from the list.
7 Specify an offset distance for the X, Y, Start, or End.
8 Click OK.
Removing a Mullion Definition from a Door and Window Assembly Style
Use this procedure to remove a mullion definition that you no longer need. You cannot remove a mullion definition
if it is assigned to a mullion, but you can remove it if it is assigned as an override to a mullion. Also, you cannot remove
the Default Mullion definition, but you can modify it as needed.
NOTE For information about removing mullions from between cells, see
Assembly Grid" on page 948.
1 On the Format menu, click Style Manager.
2 Expand Architectural Objects, and expand Door/Window Assembly Styles.
3 Select a door/window assembly style.
4 Click the Design Rules tab.
5 In the left pane, select Mullions under Element Definitions.
6 Select the unneeded mullion definition from the list.
Description
For vertical mullions, a positive X offset moves the mullions toward
the end of the door/window assembly, while a negative X offset
moves the mullions toward the start of the door/window assembly.
For horizontal mullions, a positive X offset moves the mullions toward
the top of the door/window assembly, while a negative X offset
moves the mullions toward the bottom of the door/window assembly.
In Plan view, a positive Y offset moves the mullions above the
baseline, while a negative Y offset moves the mullions below the
baseline.
Negative Start offset lengthens the mullions beyond the start point,
while a positive Start offset shortens the mullions.
Negative End offset lengthens the mullions beyond the end point,
while a positive End offset shortens the mullions.
Removing Mullions from a Door and Window
Door and Window Assembly Styles | 935
