A temporary profile is created for you to edit the geometry of the sweep.

3 Select the Edge grip, press

The wall sweep profile edge is now an arc.

1 NOTE After you perform an editing task from the shortcut menu, you may need to select the profile again to

perform another editing task. If you do not see the editing commands that you expect on the shortcut menu,

select the profile, and right-click to display the shortcut menu.

Moving an edit in-place wall sweep vertex

Edit the profile:

If you want to

change the location of the sweep

twice, and specify a new grip location.

select the Insertion Point grip, and move it to the desired

Working with Wall Sweeps | 705
