The Add Infill worksheet displays.
4 Select the insertion method for the door, window or door/window assembly:
If you want to
add the door, window or door/window
assembly as a cell assignment and have all
curtain wall units using the same style display
the same object added in a corresponding
cell
add the door, window or door/window
assembly exclusively to the selected curtain
wall unit
If a door, window or door/window assembly of the style you selected already exists in your drawing, Existing
Infill is selected by default.
5 Select the type of infill for the door, window or door/window assembly:
If you selected
Add as Cell Assignment and you want to
insert a door, window or door/window
assembly of the existing style, Existing Infill
is selected by default.
Add as Cell Assignment and you want to
insert a door, window or door/window
assembly of a different style than exists in
your drawing
Add as Cell Override and you want to insert
a door, window or door/window assembly
of the existing style and not modify the edge
of the frame surrounding the object
Add as Cell Override and you want to insert
a door, window or door/window assembly
of a different style than exists in your drawing
and not remove an edge of the frame
surrounding the object
Add as Cell Override and you want to insert
a door, window or door/window assembly
of the existing style and remove an edge of
the frame surrounding the object
866 | Chapter 19 Curtain Walls
Then
select Add as Cell Assignment.
select Add as Cell Override.
Then
Click OK.
select New Infill, enter a name for the object and click OK.
Click OK.
select New Infill, enter a name for the object and click OK.
select Top, Bottom, Left, or Right for Override Frame Removal and click OK.
