2 Create the tool:
If you want to
create a tool from a structural member style in the Style
Manager
create a tool from a brace in the drawing
copy a tool in the current palette
copy a tool from another palette
copy a tool from the Content Browser
3 Right-click the new tool, and click Properties.
4 Enter a name for the tool.
5 Click the setting for Description, enter a description of the tool, and click OK.
The description displays in the tooltip when you select the tool from the tool palette, and describes the
tool if you store it in a tool catalog in the Content Browser.
6 Expand Basic, and expand General.
7 Enter a description of the braces that you can create using this brace tool.
8 If you do not want to use the layer assignments specified in the layer key style used in the drawing, specify
a layer key and any layer key overrides.
9 Select a structural member style, and select a style location, if not the current drawing.
The style provides the shape of the brace.
10 Specify a value for Bound spaces:
If you want to
allow the brace to be used as a bounding object for associative
spaces
prevent the brace from being used as a bounding object for
associative spaces
use the bounding setting from the brace style
NOTE For more information on associative spaces, see
11 Specify a value for Trim automatically:
If you want
the geometry of the brace to be automatically trimmed to
any other structural members, other architectural objects, or
linework to which it is logically connected
prevent the geometry of the brace from being trimmed
automatically
use the trim setting from the brace style
Then
on the Format menu, click Style Manager. Locate the style
you want to copy, and drag it to the tool palette. Click OK
to close the Style Manager.
select the brace, and drag it to the tool palette.
right-click the tool, and click Copy. Right-click, and click Paste.
open the other tool palette, right-click the tool, and click
Copy. Reopen the palette where you want to add the tool,
right-click, and click Paste.
open the Content Browser, and locate the tool you want to
copy. Position the cursor over the i-drop handle, and drag
the tool to the tool palette.
Then
select Yes.
select No.
select By Style.
Generating Associative
Then
select Yes.
select No.
select By Style.
Creating a Brace Tool | 1381
Spaces" on page 1587.
