5 Save the changes to the profile:
If you want to
change the existing profile definition to reflect the new shape
create a new profile definition with the shape you have
created
discard all changes on the profile and revert back to the
previous shape
In-Place Editing of Door and Window Assembly Frames and Mullions
Use this procedure to edit frames and mullions using in-place editing with the Edit Grid grip. With in-place editing,
you can edit bays, columns or nested grids of the door/window assembly directly and interactively in the drawing area,
and later save the changes to the door/window assembly or door/window assembly style.
1 Select a door/window assembly on which you want to edit frames or mullions with in-place editing.
2 Specify the mode in which to edit the door/window assembly:
3 Specify the mode in which to edit the door/window assembly:
If you want to edit
this instance of the door/window assembly
the door/window assembly style
4 Click the Edit Grid grip.
5 Enter f (Frame and mullion assignment) and press
NOTE You have entered the in-place editing session now. You can see this from the faded color of all objects in
the drawing, as well as from the different grips at your disposal. Note that while you are in the in-place editing
session, you have only limited editing access to other commands in the drawing. Before working on other objects,
you should first end the in-place editing session.
6 Select the bay, column or nested grid to modify the frame and mullion assignment and press
Press
CTRL
The Modify Frame/Mullion Assignment worksheet displays.
964 | Chapter 20 Door and Window Assemblies
to select multiple bays, columns or nested grids.
Then
click on the In-Place Edit toolbar.
select the profile, right-click, and click Save As New Profile.
Then, enter a name for the new profile and click OK. The in-
place edit session is exited and the new profile definition is
available in the Style Manager.
click on the In-Place Edit toolbar.
Then
right-click, and click Design Rules
right-click, and click Design Rules
Rules. If this option is not available, the design rules are
already style-based for the door/window assembly.
.
ENTER
Transfer to Object.
Revert to Style Design
.
ENTER
