9 Specify whether to add or edit a block component:
If you want to
add a new block component
edit an existing block component
10 Click Select Block.
11 Select the block to use, and click OK.
12 Specify whether to scale to fit the block component to the object by width, depth, or height, or to lock the
XY ratio:
If you want to
set the block scale to the width of the object
set the block scale to the depth of the object
set the block scale to the height of the object
scale the whole block equally, so that one direction is scaled
to fit another of the scale criteria
scale the block to its original size
13 Specify whether to mirror the block in the X,Y, or Z direction:
If you want to
create a mirror of the block in the X direction
create a mirror of the block in the Y direction
create a mirror of the block in the Z direction
14 Specify the X, Y, and Z location of the insertion point.
15 Specify an insertion offset of the block in the X, Y, and Z directions.
16 Specify whether the component is for the door frame, leaf or glass:
If you want to
add the block to the inside or outside of the frame
add the block to all leaf components or to a single leaf
component
add the block to all glass components or to a single glass
component
17 Leaf and glass components are not available in some display representations.
Click OK three times.
Turning Off Custom Components in a Door Style
Use this procedure to turn off custom blocks in a door style.
Then
click Add.
select the component to edit, and click Edit. Proceed to step
11.
Then
select Width.
select Depth.
select Height.
select Lock to XY Ratio.
clear all options under Scale to Fit.
Then
select Mirror X.
select Mirror Y.
select Mirror Z.
Then
click Frame Component, and click either Outside or Inside.
click Leaf Component, and click either All or Single. If you
select Single, enter the component number.
click Glass Component, and click either All or Single. If you
select Single, enter the component number.
NOTE If you specified Depth for Scale to Fit, the depth will
be scaled to the glass thickness. You can scale to the door
panel thickness instead by selecting Scale Depth to Panel
Thickness.
