Specifying the Riser Numbering Display of a Stair Style

Use this procedure to define the display of riser numbers for a stair style.
1 Open a tool palette that has a stair tool.
2 Right-click a stair tool, and click Stair Styles.
3 Select the stair style that you want to change.
4 Click the Display Properties tab.
5 Select the display representation where you want the changes to appear, and select Style Override.
6 If necessary, click
7 Click the Riser Numbering tab.
8 Select the riser numbering display properties for the stair style:
If you want to
change the text style of the riser numbers
change the alignment of the riser numbers
change the orientation of the riser numbers
change the text height of the riser numbers
change the location to which the numbers are justified
change the location of the numbers along the length of the
stair flight
change the location of the numbers to the left or right
set the first number for the riser numbering
number the last riser in the stair
9 Click OK twice.
.
Specifying the Riser Numbering Display of a Stair Style | 1245
Then
select Cut Plane - Opposite for Apply to.
select a path for Display Path.
under Break Mark, select a mark for Type.
select Custom Shape for Type, and then select a block for
Block.
Then
select an option for Type. The available options are None,
Curved, Zigzag, and Custom Shape.
select Custom Shape for Type, and select the desired name
for Block.
Then
select a style for Text Style, or click
select an alignment for Text Alignment.
select an orientation for Text Orientation.
enter a value for Text Height.
select Left, Center or Right for Justify to.
enter a value for X Offset. This is relative to the selected
position of the riser.
enter a value for Y Offset. This is relative to the selected
position of the riser.
enter a value for First Riser Number.
select Number Final Riser.
to edit the text style.
