To change the cut plane display properties for all walls of the same wall style, see
Components of a Wall Style" on page 734.
1 Select the wall you want to change, right-click, and click Edit Object Display.
NOTE You can also use the Display tab of the Properties palette to change the display property settings for a
selected object display component in the current display representation. For more information, see
Properties Palette to Change Display
2 Click the Display Properties tab.
3 Select the display representation where you want the changes to appear, and select Object Override.
The display representation in bold is the current display representation.
4 If necessary, click
5 Click the Cut Plane tab.
6 To specify the cut plane where shrinkwrap, component boundaries, and hatching take effect, enter a value
for Cut Plane Height.
7 To show the components above and below the cut plane height, select Automatically Choose Above and
Below Cut Plane Heights.
8 To specifically define a cut plane, select Manual Above and Below Cut Plane Heights, click Add, and enter
the height of the new cut plane.
If you add a cut plane
at a height that is lower than the value for Cut Plane Height
at a height that is higher than the value for Cut Plane Height
You can click Remove to delete a cut plane that you added.
9 Click OK twice.
Specifying the Display of Other Characteristics of a Wall
Use this procedure to specify other display properties for an individual wall, such as whether to display complex endcaps,
to show door and window frames, or whether to show the miter of specific wall components. These display properties
apply only to display representations, such as Plan, that are used in the Top view (plan view) of a drawing.
To change these display properties for all walls of the same wall style, see
Style" on page 733.
1 Select the wall you want to change, right-click, and click Edit Object Display.
NOTE You can also use the Display tab of the Properties palette to change the display property settings for a
selected object display component in the current display representation. For more information, see
Properties Palette to Change Display
2 Click the Display Properties tab.
3 Select the display representation where you want the changes to appear, and select Object Override.
The display representation in bold is the current display representation.
4 If necessary, click
5 Click the Other tab.
Properties" on page 445.
.
Properties" on page 445.
.
Changing the Display Properties of Individual Walls | 685
Specifying the Hatching for
Then
objects are displayed using the properties specified for the
Below Cut Plane component on the Layer/Color/Linetype
tab.
objects are displayed using the properties specified for the
Above Cut Plane component on the Layer/Color/Linetype
tab.
Specifying the Display Properties of a Wall
Using the
Using the
