5 To attach, detach, or edit a reference file, click
following:
If you want to
attach a reference file
edit the description of a reference file
edit a reference file
detach a reference file
6 Click OK.

AEC Polygon Styles

An AEC Polygon style is a group of properties that determines the appearance and other characteristics of AEC Polygons.
AEC Polygon styles control the following parameters:
default dimensions, including edge width and justification
default display properties for the interior and edges of the AEC Polygon
The display properties of an AEC Polygon allow you to hatch its interior and edges, or fill its edges and interior
with a solid color fill.
masking capability
Creating Tools from AEC Polygon Styles
You can create an AEC Polygon tool from any AEC Polygon style. You can drag the style from the Style Manager onto
a tool palette. You can then specify default settings for any AEC Polygon created with that tool. For more information,
see Using AEC Polygon Tools to Create AEC
Managing AEC Polygon Styles
To create, copy, or edit styles, you access the Style Manager. The Style Manager provides a central location in AutoCAD
Architecture where you can work with styles from multiple drawings and templates. For more information, see
Manager" on page 490.

Creating an AEC Polygon Style

Use this procedure to create an AEC Polygon style. You can create a new style using default style properties, or by
copying an existing style. After you create a style, you edit its properties to customize the characteristics of the style.
1 On the Format menu, click Style Manager.
2 Expand Multi-Purpose Objects, and expand AEC Polygon Styles.
3 Create an AEC Polygon style:
If you want to
create a style with default properties
create a style from an existing style
4 To rename the new AEC Polygon style, right-click the style, and click Rename.
5 Enter a name for the new AEC Polygon style, and press
994 | Chapter 21 AEC Polygons
to Reference documents, and then do any of the
Then
click
enter text under Description.
double-click the reference file name to start its application.
select the file name, and click
Polygons" on page 979.
Then
right-click AEC Polygon Styles, and click New.
right-click the AEC Polygon style you want to copy, and click
Copy. Right-click, and click Paste.
ENTER
, select a file, and click Open.
.
.
Style
