Chapter 4 ALERT Library Management
Library Status
Library Status
Accessing Library
4
Status
Table 7 Library Status
Fields
34 Tandberg Data M-Series Remote Management Card User's Guide
The page allows you to view the general status of the
Library Status
library and to move cartridges within the library.
To view the current library status, from the navigation frame of the
Management Console
status icon.
The management frame displays the read-only
including the current status of the library, and where applicable,
individual frames and levels. See
fields.
This page remains blank while the
Note:
library for status. The page will periodically go blank
while the information refreshes.
On an M2500 Library Status page, placing the cursor over a section
of the library picture indicates the frame number and the level
within the frame.
Field Description
Frame Individual links to the frames in a multiframe library
Level Defines a section of a frame in an M2500 library.
Drive Each drive may be accessed for more detailed
information. See
on page 38. Press on the corresponding drive number
to access the element information.
Elevator Only available in multi-frame libraries. Displays the
status of the elevator. There is only one elevator per
multi-frame library.
page, press
Home Library Status
table 7 for a description of the
Viewing Drive Element Information
, or press the
page,
Library Status
queries the
RMC
