JUNOSe 11.1.x Physical Layer Configuration Guide
show controllers t1
show controllers t3
30
Monitoring Interfaces
Use the optional delta keyword with the show interfaces serial commands to
view the baseline statistics.
Example
host1#baseline interface serial 2/0:1/1
There is no no version.
See baseline interface.
Use to display data and MIB statistics for a T3 interface or a T1 channel.
Use the brief keyword to display the administrative and operational status of all
configured T3 interfaces, or to display abbreviated information for the specified
T3 interface.
For definitions of the MIB statistics for a T3 interface, see RFC 2496 Definitions
of Managed Objects for the DS3/E3 Interface Types (January 1999).
For definitions of the MIB statistics for a T1 channel, see RFC 2495 Definitions
of Managed Objects for the DS1, E1, DS2 and E2 Interface Types (January 1999).
Field descriptions for T3 interface (T1 channel not specified)
Description Text description or alias if configured for the interface
ifAdminStatus One of the following administrative states of the interface:
ifAdminUp Interface is administratively enabled
ifAdminDown Interface is administratively disabled
ifAdminTesting Interface is administratively configured in a testing
state
snmp trap link-status—Status of SNMP trapping (enabled or disabled)
alarms detected One of the following T3 alarms:
No alarm present No alarms present on the line
Rcv RAI Failure Remote device is sending a far end alarm failure
Xmt RAI Failure Local device is sending a far end alarm failure
Rcv AIS Remote device is sending an alarm indication signal (AIS)
Xmt AIS Local device is sending an AIS
Rcv LOF Loss of one or more frames from the remote end
Rcv LOS Loss of signal at the local end
Undefined line status Indicates that the line is in an undefined state
