show controllers sonet ds3
Received bit count = 41472000
Error bit count
= 0
Number of valid interval - 0
Time elapse in current interval - 0
Current Interval Counters
Errored seconds
Severely errored second
Severely errored frame seconds
Unavailable seconds
Clock slip seconds
Path code violations
Line errored seconds
Bursty errored seconds
Degraded minutes
Line code violations
24 Hour Total Counters
Errored seconds
Severely errored second
Severely errored frame seconds
Unavailable seconds
Clock slip seconds
Path code violations
Line errored seconds
Bursty errored seconds
Degraded minutes
Line code violations
See show controllers sonet.
Use to display T3 statistics for the different layers in channelized SONET and
SDH interfaces. Figure 8 on page 113 shows the layers in the interface.
For definitions of the MIB statistics, see RFC 2496 Definitions of Managed
Objects for the DS3/E3 Interface Types (January 1999).
Specify an interface in slot/port format.
To view information for a specific controller in a layer, enter the specifier for the
controller and the type for the controller. For example, to view T3 controller 1
on path 1 on the interface 4/0, enter show controllers sonet 4/0:1/1 ds3.
To view information for all controllers above a particular layer, enter the specifier
for the layer and the type for the controller. For example, to view all DS3
controllers on the interface 4/0, enter show controllers sonet 4/0 ds3.
To view T3 statistics for a layer, specify the controller type, ds3.
To view the configuration for a controller or all controllers in a layer, omit the
controller type.
Field descriptions
Description Text description or alias if configured for the interface
BERT test Number of current test and total number of tests
Chapter 4: Configuring Channelized OCx/STMx Interfaces
= 0
= 0
= 0
= 0
= 0
= 0
= 0
= 0
= 0
= 0
= 0
= 0
= 0
= 0
= 0
= 0
= 0
= 0
= 0
= 0
Monitoring Interfaces
