show controllers sonet
Use the total [ delta ] keywords with the show controllers sonet section
commands to view the baseline statistics.
Example 1 Sets a baseline for SONET section layer interfaces on ERX14xx
models, ERX7xx models, or the ERX310 router
host1#baseline section interface sonet 2/0
Example 2 Sets a baseline for SONET section layer interfaces on the E320
router
host1#baseline section interface sonet 3/0/0
There is no no version.
See baseline section interface sonet.
Use to display the configuration for SONET and SDH interfaces.
Field descriptions
Interface specifier in slot/port format (ERX14xx models, ERX7xx models,
and the ERX310 router) or slot/adapter/port format (E120 and E320 routers)
non channelized Unchannelized path
channelized Number of channels and speed for the interface
ifAdminStatus Configured status of the interface: up or down
description Configured description of the controller
snmp trap link-status State of SNMP link-status processing for the section
and line layers of the interface: enabled or disabled
alarms used for operational status calculation Types of defects that the
router uses to determine the operational status of the interface at the section
and line layers
defect trigger soaking delay Time that the router waits to set an alarm
when the router records a defect at the section or line layer
Operational Status Physical state of the interface:
up Interface is operational
down, failure alarm Interface is not operational; type of defect that
caused failure is specified
time since last status change Time since the module was rebooted
Loopback State Type of loopback configured on the interface
Mode Type of interface: SONET or SDH
Timing source Type of clock source configured for the channel:
line Internal clock is from the line module itself
Chapter 3: Configuring Unchannelized OCx/STMx Interfaces
Monitoring SONET/SDH Interfaces
99
