JUNOSe 11.1.x Physical Layer Configuration Guide
controller t3
shutdown

Configuring MDL Messages

You can configure a T3 interface to send MDL messages. MDL messages are supported
only when T3 framing uses C-bit parity, the default setting.
To configure a T3 interface to send MDL messages:
1.
2.
3.
52
Configuration Tasks
slot Number of the slot in which the line module resides in the chassis
port Number of the port on the I/O module
Example
host1(config)#controller e3 3/2
There is no no version.
See controller e3.
Use to specify a T3 controller in slot/port format.
slot Number of the slot in which the line module resides in the chassis
port Number of the port on the I/O module
Example
host1(config)#controller t3 0/1
There is no no version.
See controller t3.
Use to disable a T3 or an E3 controller.
The T3 or E3 interface is disabled by default.
Example
host1(config-controll)#shutdown
Use the no version to restart a disabled interface.
See shutdown.
Specify a T3 interface.
host1(config)#controller t3 8/0
(Optional) Configure the interface to operate in an MDL carrier environment.
host1(config-controll)#mdl carrier
Specify the MDL messages.
