equipment loopback
NOTE: Remote loopback is available only on channelized T3 interfaces configured
to use C-bit framing.
loopback
NOTE: Remote loopback is available only on channelized T3 interfaces configured
to use C-bit framing.
Use to enable or disable the router's ability to enter into a loopback initiated by
a remote device connected on a channelized T3 interface.
Specify one of the following loopback options:
customer Enables the router to enter into loopback when it receives an
appropriate signal from the remote interface
network Disables the router's ability to enter into loopback when it receives
an appropriate signal from the remote interface
Examples
host1(config-controll)#equipment customer loopback
host1(config-controll)#equipment network loopback
Use the no version to disable the router's ability to be placed in loopback by the
remote device.
See equipment loopback.
Use to configure a loopback.
Specify one of the following loopback options.
local Loops the data back toward the router; on supported line modules,
also sends an alarm indication signal (AIS) out toward the network
network Loops the data toward the network before the framer processes
the data
payload Loops the data toward the network after the framer processes the
data
remote Sends a far end alarm code in the C-bit framing, as defined in ANSI
T1.404, to notify the remote end to activate or (when you use the no version)
deactivate the line loopback
Example
host1(config-controll)#loopback local
Chapter 1: Configuring Channelized T3 Interfaces
Testing Interfaces
25
