Power supply specifications

AC VOLTAGE:
18 - 60 VDC/AC (on request); 90 - 260 VDC/AC (standard)
POWER CONSUMPTION:
30VA / 12W (90-260V); 20VA / 12W (18-60V)

General specifications

OPERATING TEMPERATURE:
from 0 to +50 C (R.H. <90% non-condensing)
STORAGE TEMPERATURE:
from -10 to +60 C (R.H.<90% non-condensing).
INSULATION REFERENCE VOLTAGE:
300 VRMS to earth
INSULATION: 4000 VRMS between inputs/outputs and earth
DIELECTRIC STRENGTH: 4000 VRMS for 1 minute
COMMON MODE REJECTION (CMRR): 100dB, from 48 to
62 Hz
EMC: EN 50081-2, EN 50082-2
OTHER STANDARDS:
• Safety: IEC 61010-1, EN 61010-1
• Product: IEC 60688-1, EN 60688-1,
• Energy measurement: EN61036, EN61268.
• Pulse output: DIN43864
APPROVALS:
CE, UL, CSA
CONNECTIONS:
Screw-type, max 2.5 mm
HOUSING:
Dimensions: 96 x 96 x 140mm
Material: ABS, self-extinguishing: UL 94 V-0
DEGREE OF PROTECTION: Front: IP 65
WEIGHT: 600 g approx (packing included)
RS485 Serial output
56
Technical features
2
52
x 2 conductors
