Outputs / Other settings
The EURO/USA function allows the user to display
the date and time according to the EUROPEAN
(EURO, date: day/month/year; time: 24 hours) or
AMERICAN (USA, date: month/day/year; time: 12
hours / AM and PM) format.
Holiday period
25

Clock setting

This function enables the user to set
the data relating to date and time.
Select CLOCK from the main menu
by means of the
then press
Choose the desired function by means
of the and
desired secondary menu with
Then set the desired value by means
of the and
the value with
choices and go back to the main
menu, press
Digital outputs
This function enables the user to
connect the type of digital output to
the slot at the beginning. The instru-
ment indicates if the module is not in
the slot with the message "NOT
AVAILABLE"; whereas if the module
is in the slot, the instrument auto-
matically goes to the digital output
menu, where the user can set four
different types of output:
PULSE OUTPUT, ALARM OUTPUT,
29 37
and
to enter the menu.
keys; Enter the
keys and confirm
. To reset the
.
Alarms
32
keys;
.
