To Begin With; The Main Programming Parameters - CARLO GAVAZZI WM3-96 - PROGRAMMING Instruction Manual

Main programming parameters
• Programming of the password
• Selection of the electrical system
• Programming of the CT ratio (up to 30,000 A)
• Programming of the VT ratio (up to 600kV)
• Selection of the variables for the MIN / MAX detection
• Programming of the calculation of the integration time period
• Tariff management
• Harmonic analysis enabling
• Clock adjustment (if present)
• Programming of the pulse output (if present)
• Programming of the serial and analogue outputs (if present)
• Programming of the digital filter.
