Displaying of the variables
Page "27" (14 in single phase mode)
Displaying of instrument configuration
key disabled. Page 27 shows the configuration of the main
input (IN) and output (OUT) modules.
Alarms
(A1-A2-A3-A4).
Diagnostics
(D1-D2-D3-D4).
Pulse outputs
(P1-P2-P3-P4).
Digital inputs.
The letters and numbers between parenthesis are referred to
the relevant slot, while the text on their right shows the variable
referred to the output. With reference to the digital inputs
(DIG.INP.), the ON/OFF status of each one of them is shown.
Displaying with access to the Pass Code
Pass "1000": displaying of recorded events
(Only if the RS232+RTC module is present)
Press the
code
module is present, the instrument shows you the page where
the events are displayed and where the instrument stores, in
a chronological order, the alarms that have occurred until that
moment. To go back to the variable page press the
The last event has always the number 1 while the number
corresponding to the first event varies, depending on the
number of events that have been previously stored. The figure
on the following page explains you the meaning of the dis-
played information.
Harmonic analysis
9
key: when the instrument asks you for the pass
, set the value "1000"; if the RS232+RTC
7
12
11
key.
CT ratio
15
