Alarms - CARLO GAVAZZI WM3-96 - PROGRAMMING Instruction Manual

32
Outputs / Other settings
The multiplyer of the measuring unit (kW,MW)
automatically changes according to the CT or VT
ratio set by the user.
Select the desired variable by means of the
keys, press
to the various parameters:
•VARIABLE: variables to be connected to the alarm: you can
Multi-tariff
27
consumed active energy (kWh +),
generated active energy (kWh -),
consumed reactive energy (kvarh +),
generated reactive energy (kvarh -),
press the "
of energy/pulse output management.
There are five possible selections:
TOTAL, output connected to the total
energy meter; TARIFF, output con-
nected to the desired tariff type.
Confirm with
digital output menu. To reset the
choices and go back to the main menu,
press

Alarms

This function allows the activation of
a static or relay output when an alarm
condition is detected. Select ALARM
from the DIGITAL OUTPUT menu
by means of the
then press
window of all the alarm parameters:
to confirm and enter the submenus dedicated
29
" key to open the menu
and go back to the
.
to enter the display
37
and keys,
and
Diagnostic
34
