Outputs / Other settings
•MIN IN: minimum value of the variable input range. Select the
desired value by means of the
confirm it with
•MAX IN: maximum value of the variable input range. Select the
desired value by means of the
confirm it with
. For further information, see examples No. 1 and 2 on
page 38/39. For the resolution of the value to be
retransmitted, see the note on page 33.
Every time a new selection of the variable con-
nected to the analogue output is made, it is
important to check and if necessary program
again all the relevant parameters.
1.2..
..2.1
Pulse outputs
31
.
. To exit from any of the menus, press
Serial output
This function allows the user to set
the parameters of the serial output.
Select SERIAL OUTPUT from the
main menu by means of the
keys and confirm it with
Select the function you want to set
from one of the submenus by means
of the and
it with . The configurable param-
eters are the following:
• Instrument ADDRESS: from 1 to 255.
• BAUD RATE: 1200, 2400, 4800
and 9600 bit/s.
• PARITY: no parity, even parity and
odd parity. To exit from one of the
menus or cancel a selection, press
.
29
37
and
and
keys and confirm
Useful information
keys and
keys and
and
.
