TARIFF SELECTION
TARIFF SELECTION
When you change the type of management, and
after the choice is confirmed, the instrument re-
sets the meters and a buzzer sounds.
Dual tariff management of the meters: whole year
This selection manages the energy meters with two different
tariffs per day and two periods per year. Select DUAL TARIFF
from the energy meters menu by means of the
keys and confirm with
with to enter the relevant menu; now you can enter the
programming of the daily period as follows:
1- press : the first box (trf=tariff) is highlighted;
2- press
part of the display; now you can choose the tariff (from 1 to 4,
e.g.: 1) by means of the
Min/Max values
17

Energy Meters Management

This function allows you to choose
the type of management of the en-
ergy meters. Select "ENERGY ME-
TERS" from the main menu by
means of the
confirm with
cific secondary menu.
This function sets the Energy meters
according to a single tariff which is
the same for the whole year.
Select SINGLE TARIFF by means of
the
your choice with
. Select WHOLE YEAR and confirm
again: the TARIFF box will appear on the lower
Access to the Energy
Meters Management Menu
Single tariff
and
and keys;
Energy Meters Management
28
and keys;
to access the spe-
keys and confirm
.
and
