This function allows you to choose
the desired password value (from 0
to 500).
Press the
new password value is required,
enter the desired value by means of
the
The instrument goes back to the
main menu, as shown on the figure
on the left. To reset your choices and
1.2..
..2.1
go back to the main menu press
This function allows the user to se-
lect the type of electrical system by
choosing among single phase (1-
phase), balanced three-phase plus
neutral (3+N phases bal.), unbal-
anced three-phase plus neutral
(3+N phases unbal), three-phase
balanced (3 phases bal) and three-
phase unbalanced (3 phases unbal).
Choose the SYSTEM function by
means of the
press
desired system by means of the
and
13

Changing the password

and
System
to confirm; then select the
keys and confirm with
21
key and when the
keys.
and
VT ratio
16
.
keys,
.
