CARLO GAVAZZI WM3-96 - PROGRAMMING Instruction Manual page 3

4
Index
V/mA single analogue outputs .......................... 49
V/mA dual analogue outputs ............................. 49
Relay output ..................................................... 50
Open collector output ....................................... 50
Digital inputs ..................................................... 50
RS485 serial output .......................................... 51
ELECTRICAL DIAGRAMS ............................................... 52
Electrical connection diagrams ............................... 52
Three-phase connection, Balanced load .......... 52
4-wire three-phase connection, unbalanced load 53
3-wire, three-phase Aron connection , ..................
unbalanced load ................................................ 54
Single-phase connection .................................. 55
TECHNICAL FEATURES ................................................. 56
General features ..................................................... 56
Input specifications ................................................. 56
Over-load protection ............................................... 58
Key-pad ................................................................. 58
Output specifications ............................................... 58
Software functions .................................................. 61
Harmonic distortion analysis ................................... 62
Energy Management ............................................... 63
Power supply specifications .................................... 64
General specifications ............................................. 64
HOW TO USE THE SYMBOLS
Go to the page where the previous main
subject is described.
Go to the page where the next main subject
is described.
Go to the page where the subject written
on the top of the current page starts.
2
Front panel description
6
