Remote Control - CARLO GAVAZZI WM3-96 - PROGRAMMING Instruction Manual

34
Outputs / Other settings
Display of harmonics
29
Diagnostic
In a 3-phase unbalanced-load sys-
tem, this function controls the
presence of the neutral connection.
If the connection to the neutral is not
detected, the instrument activates
an alarm. Select "DIAGNOSTIC" by
means of the
press to confirm it. To reset your
choice and go back to the main menu,
press .

Remote control

This function enables the control of
the digital outputs by means of the
RS485/RS232 communication port
instead of using the instrument's
alarm. The outputs can be activated
by a PC or PLC by sending special
commands. Select the REMOTE
CONTR. function by means of the
and
ing the
go back to the digital output menu.
To reset your choice and go back to
the main menu, press
29 37
and
keys and confirm press-
key: the instrument will
Serial output
keys, then
.
36
