■ Installing the UT-133A
When you install the optional UT-133A Bluetooth
the transceiver, you can communicate with other Bluetooth
headset.
NOTE: Before touching the transceiver or UT-133A,
remove static electricity from your body by touching a
grounded object such as a grounded piece of equipment.
The static electricity from your body may damage the
transceiver or the UT-133A, or cause data lost.
R WARNING! BE SURE TO disconnect the DC power
cable before starting the following procedures.
1. Turn the transceiver upside-down.
2. Remove the three screws from the bottom of the
transceiver and the four screws from the sides, then lift
off the bottom cover.
Bottom
cover
3. Place one end the UT-133A under the edge of the front
panel, with the connector facing down.
in
unit
Front panel
4. Carefully, push the connector into the socket.
• Ensure the UT-133A is installed correctly.
5. Reattach the bottom cover and screws.
Bluetooth ® OPERATION
UT-133A
Connector
