14. Rotate [DIAL]S to select a desired number.
15. Push [◄] to move the cursor backwards, or push [►] to
move the cursor forwards.
16. Repeat steps 14 and 15 to enter a lower edge frequency.
(Example: 375.000)
17. After entering, push [ï]D.
18. Rotate [DIAL]S to select "FREQ H," and enter a higher
edge frequency in the same way as steps 13 and 15.
19. After entering, push [ï]D.
3. Setting a tuning step
NOTE: If the frequencies entered in "FREQ L" and "FREQ
H" are on a different band, the Tuning step setting screen
is not displayed. In this case, the VFO mode's tuning step
for each band is used during a scan.
20. Rotate [DIAL]S to select "TS."
21. Push [ï]D to display the Tuning step setting screen.
22. Rotate [DIAL]S to select a desired tuning step to be
used while program scanning.
Selectable value (kHz):
5.0, 6.25, 8.33*, 10.0, 12.5, 15.0, 20.0, 25.0, 30.0, 50.0,
or AUTO*.
* Displayed only when the AIR band is selected.
23. After selecting, push [ï]D.
4. Setting a operating mode
NOTE:
• If the frequencies entered in "FREQ L" and "FREQ H" are
• When the entered frequencies are in the AIR band, the
Lower edge frequency
setting screen
24. Rotate [DIAL]S to select "MODE."
25. Push [ï]D to display the Operating mode setting screen.
26. Rotate [DIAL]S to select a desired operating mode.
27. After selecting, push [ï]D.
5. Entering the scan edge
28. Rotate [DIAL]S to select "WRITE."
29. Push [ï]D.
30. Rotate [DIAL]S to select "YES."
31. Push [ï]D.
The C, S, or D in the instructions indicate the area of the
controller.
C: Center, S: Side, D: Display
SCAN OPERATION
on a different band, the Operating mode setting screen
is not displayed. In this case, the VFO mode's operating
mode for each band is used during a scan.
operating mode is automatically set, and the setting
screen is not displayed.
• Displays "WRITE?."
• Beeps sound.
• Enters the scan edges, and returns to the Scan edge channel
select screen.
